• Country of Origin:

    • Taiwan

    Key Specifications/Special Features:

    • CREM0603 series:
      • Inductance (nH): 3.9+/-10% ~ 56.0+/-10%
      • Test condition: 300MHz
      • Q min: 70
      • DCR (mohm) max: 3.0 ~ 38.0
      • IDC (mA) max: 300 ~ 950
      • SRF (MHz) min: 1500
      • Packing reel: 4000

    • CREM0805 series:
      • Inductance (nH): 3.9+/-10% ~ 56.0+/-10%
      • Test condition: 300MHz
      • Q min: 70
      • DCR (mohm) max: 2.6 ~ 38.0
      • IDC (mA) max: 300 ~ 950
      • SRF (MHz) min: 1500
      • Packing reel: 4000

    • CREM1008 series:
      • Inductance (nH): 6.8+/-10% ~ 100+/-10%
      • Test condition: 300MHz
      • Q min: 70
      • DCR (mohm) max: 4.0 ~ 55.0
      • IDC (mA) max: 300 ~ 950
      • SRF (MHz) min: 1500
      • Packing reel: 4000

    • CREM1008F series:
      • Inductance (nH): 150+/-10% ~ 1000+/-10%
      • Test condition: 25.2 ~ 100MHz
      • Q min: 25
      • DCR (mohm) max: 15.0 ~ 100.0
      • IDC (mA) max: 240 ~ 500
      • SRF (MHz) min: 350 ~ 850
      • Packing reel: 4000

    • CRM0603 series:
      • Inductance (nH): 3.9+/-10% ~ 56.0+/-10%
      • Test condition: 300MHz
      • Q min: 70, 80
      • DCR (mohm) max: 3.0 ~ 38.4
      • IDC (mA) max: 300 ~ 950
      • SRF (MHz) min: 1300 ~ 3000, >3000
      • Tape: 0603L-A, B
      • Packing reel: 4000

    • CRM0805 series:
      • Inductance (nH): 3.9+/-10% ~ 68.0+/-10%
      • Test condition: 300MHz
      • Q min: 70, 80
      • DCR (mohm) max: 2.6 ~ 42.2
      • IDC (mA) max: 320 ~ 1200
      • SRF (MHz) min: 1300 ~ 3000, >3000
      • Tape: 0805L-A, B
      • Packing reel: 4000

    • CRM1008 series:
      • Inductance (nH): 6.8+/-10% ~ 120+/-10%
      • Test condition: 300MHz
      • Q min: 70, 80
      • DCR (mohm) max: 4.0 ~ 63.4
      • IDC (mA) max: 320 ~ 1200
      • SRF (MHz) min: 950 ~ 3000, >3000
      • Tape: 1008L-A, B
      • Packing reel: 4000

    • CRM1008F series:
      • Inductance (nH): 120+/-10% ~ 1000+/-10%
      • Test condition: 25.2 ~ 100MHz
      • Q min: 25
      • DCR (mohm) max: 15.0 ~ 112.6
      • IDC (mA) max: 240 ~ 600
      • SRF (MHz) min: 290 ~ 950
      • Tape: 1008CL/CH-A, B
      • Packing reel: 4000

    Main Export Markets:

    • Eastern Europe
    • Western Europe
